Avionic light Sonaca 200

elisa aero nyc
Protocol
  • Sonaca 200 avionic Demonstrator
  • ROHS compliant
  • Initiated by : Head of Engineering
  • PC n°: 78H-110/4389
  • Change : Français
MOBILE EDITION
Pick up / Shipping

SONACA AIRCRAFT²
ROUTE NATIONALE 5
6041 GOSSELIES
BELGIQUE

US MAIL LETTER
WEIGHT Insignificant
See parcel

Dashboard

1 Unit
SPECIFICATIONS
Length : 1,20m ± 0,1m
Width : 20 mm ± 5mm
Thickness : max 5 to 6 mm

CATEGORY
CS-VLA (CS-23 « light »)

elisa nyc
electroluminescent-airplane-dashboard
Electro luminescent organs

1  Unit
1 Native print E010²
Max résolution: 1
Luminance: 190 Cd/m²
Handmade production
Thickness: 2µm
M1F1 encapsulation: 4µm
Liner monobloc: 1 µm
Degre of flexibility +/-: 20°

Wiring

1 Unit
1 Busbar 20 cm
Apolar
Handmade fit
Degree of flexibility 360°

CONNEXION
Plug is isolated, athermic and water resistant.
Drill encapsulation film with a solder. Two small points ( mm ) are enough to create some power supply plug.

REQUIRED MATERIEL
1 Solder station + tin
Wiring
Miscellaneous

AVIATION WIRING PROVIDE FOR MASS PRODUCTION

faisceau-wire-sonaca-200
Elisa aero
Electronic

0 Unit
12 VDC Symbiote
Electromagnetic shield
ROHS regulation
Designed in United states

ELISA SYMBIOTE PROVIDED FOR MASS PRODUCTION .

Administrative

M1F1 REGULATION
M1 (PV n ° -13-02858L LYC) et F1 (PV n ° 13-02860L-LYC)
from regulation NF P 92.507.

US License
Avionic
Add New Functions

Access to more options useful in flight et extend your limits.

Start New Project

From your works office and whatever your aircraft type. May required a valid license to grant access.

Order the same prototype

All production parameters have been archived. You just have to place your order.
